| output torque: | |
|---|---|
| power: | |
| roller material: | |
| drive head: | |
| Quantity: | |
DGDD50
RONWIN
HS Code: 8431390000
DGDD50-H Direct Driven Motor Roller as for Belt Conveyor Sorting Trolley (0-15KG)
Hall External Rotor Brushless Permanent Magnet Synchronous Motor
Voltage:DC48V
Power: 116W
Revolution: 150-1050rpm
Communication: 485 CAN
Motor Duty: S2
V-type guide groove
Product Advantage: Smooth feed-in and feed-out, high precision control, quick response, adjustable acceleration and deceleration, suited for 0–15 kg cargo.
| Input Voltage | DC24V/DC48V | ||
|---|---|---|---|
| Rated Torque (N.m) | 0.5 | 1.0 | 1.5 |
| Rated Torque (N.m) | 1.5 | 3.0 | 4.5 |
| Revolution (rpm) | Power | ||
| S2: 750～S1: 1000 | 58 | 116 | 166 |
| S2: 600～S1: 800 | 46 | 93 | 133 |
| S2: 450～S1: 600 | 35 | 70 | 100 |
| S2: 300～S1: 400 | 23 | 45 | 65 |
| S1 Belt Conveyor Continous Transport Weight (KG) | 4 | 8 | 12 |
| S2 Belt Conveyor Continous Transport Weight (KG) | 8 | 16 | 24 |
| Controller | Direct connection to the power source is not possible; a separate controller must be used instead. | ||
| Response | H: Hall M: Magnetic Encoder R: Resolver Synchro | ||
Advantages of DC Direct-Driven Motor Roller
DC Direct-Driven Motor Roller-DGDD Corresponding Name of Parts
| 1. cable | 3. front bearing housing | 5. gear box | 7. tube wall | 9. end shaft |
| 2. outlet end shaft | 4. motor | 6. fixture | 8. rear bearing housing | 10. Hall chip |
