1525
RONWIN
HS Code: 8431390000
The Embedded Plug-in Type Universal Ball 1525 is a precision guiding component specifically designed for light-load material handling systems. Featuring a cylindrical plug-in body and an embedded mounting structure, it achieves seamless and streamlined equipment integration while incorporating multiple practical functions to meet the needs of diverse industrial scenarios.
| ref no. | material | loading capacity (kg) | weight | |
| suggest | max. | |||
| 1525 | CS/CS | 20 | 30 | 170 |
| PL/CS | 10 | 15 | 120 | |
| SS/SS | 15 | 20 | 170 | |
| PL/SS | 10 | 15 | 120 | |
- Developed specifically for light to medium load applications
- Compact structure, lightweight, reducing system burden
- Smooth operation, effectively lowering power consumption
- Cylindrical plug-in body for simple and quick installation
- Embedded design ensures flush integration with equipment surfaces
- Provides stable mechanical support, preventing displacement issues
- **Bottom Drainage Hole Design**: Effectively expels water, dust, and other contaminants
- Prevents internal water accumulation and corrosion, extending service life
- Suitable for challenging environments such as humid or dusty conditions
- Internally integrated spring-loaded system
- Effectively absorbs impact and vibration, protecting conveyed materials
- Ensures stable operation, reducing noise and wear
- Steel Ball Version: High strength, wear-resistant, suitable for standard industrial environments
- Plastic Ball Version: Quiet operation, corrosion-resistant, ideal for special industries like food and packaging
- Can be customized according to specific application requirements
- Easy Installation: Plug-in structure significantly reduces installation time
- Convenient Maintenance: Modular design facilitates inspection and replacement
- Strong Compatibility: Adapts to various equipment platforms and conveying systems
- Cost-Effective: Balances performance and cost, offering excellent value
- Light-duty conveyor lines, assembly line equipment
- Packaging machinery, food processing equipment
- Electronics assembly lines, automated workstations
- Medical devices, laboratory instruments
- Warehousing and logistics sorting systems
To ensure optimal performance, it is recommended to select the appropriate ball material version based on actual load conditions, environmental characteristics, and operating frequency. Regularly check the drainage holes for clear passage and keep the equipment clean.
With its refined design, reliable performance, and installation convenience, the Embedded Plug-in Type Universal Ball 1525 provides an efficient and flexible solution for modern light-load conveying systems, making it an ideal choice for enhancing equipment operational efficiency.
---
For detailed information on technical specifications, installation dimensions, or customization requirements, please contact us.
