In the logistics conveying industry, a converging conveyor is responsible for bringing goods from multiple branch lines onto a single main line, while a diverging conveyor distributes goods from the main line to different branch lines according to instructions. They are key pieces of equipment in automated logistics systems.
Beyond the mainstream types above, there are also specialized devices. For example, the bottom-belt centering converging conveyor uses an angled roller design to automatically center scattered goods during merging, preparing them for subsequent precise sorting.[reference:10] The AIM converging conveyor uses a unique push-block technology to achieve high-speed (61 m/min), gentle merging, effectively avoiding product damage, and is widely used in industries with high product appearance requirements such as food and daily chemicals.
Wide range of handled items: Modern equipment can efficiently handle not only cartons and totes, but also soft bags, woven bags, and other irregular items.[reference:12]
High sorting efficiency: Depending on the application scenario, equipment efficiency can range from 3,000 to 10,000 pieces/hour, meeting high-throughput demands.
Automation and intelligence: The system is controlled by a PLC (Programmable Logic Controller)[reference:14], identifies goods via barcode/RFID[reference:15], and seamlessly integrates with WCS/WMS.
High accuracy: In fully automatic sorting mode, system accuracy can reach 99.99%.
Modularity and flexibility: Modular design makes equipment easy to install, maintain, and expand[reference:18], and allows stepless speed adjustment to match different production rhythms.
Low noise and energy saving: Low-power designs such as accumulation rollers ensure smooth operation and relatively low noise.
Converging and diverging conveyors are the "capillaries" of logistics automation and have penetrated various industries. The table below summarizes their typical applications.
| Industry | Specific Application | Common Equipment Types | Key Value |
|---|---|---|---|
| E-commerce / Express | Parcel sorting, merging for induction, diverting by destination | High-speed diverter, belt-type diverging conveyor | Handling massive volume & irregular items |
| Tobacco / Pharmaceutical | Cigarette carton sorting, medicine box diverting | Pusher/pop-up diverter, bottom-belt centering converging conveyor | High accuracy, gentle handling |
| Food & Beverage | Packaging line merging, pre-palletizing diverting | Roller-type converging/dverging conveyor, belt-type converging conveyor | Efficiency, hygiene, product protection |
| Manufacturing | Parts distribution, finished product diverting | Roller/belt converging/dverging conveyor, vertical diverter | Rhythm matching, line balancing |
| Airport Baggage | Baggage sorting, vertical transport | Belt-type diverging conveyor, vertical diverter | High speed, low wear, high reliability |
| Retail / 3PL | Warehouse order picking, distribution center diverting | Bottom-belt centering converging conveyor, high-speed diverter | Order consolidation, space optimization |
When selecting a converging or diverging conveyor, focus on the following:
Item characteristics: Type (box/soft bag/irregular), weight range, and size range.
Throughput requirements: Handling efficiency (pieces/hour), conveying speed (m/min), and sorting accuracy.
Layout and space: Orientation (horizontal/vertical), site dimensions, and integration space.
Control and integration: Control method (PLC/industrial PC), interface protocols, and integration with host systems.
Cost and maintenance: Purchase cost, energy consumption, ease of maintenance, and spare parts availability.
We hope this detailed overview helps you better understand converging and diverging conveyors. If you are willing to share specific item types, dimensions, and target handling rates, I can help you further evaluate the most suitable equipment type.
