Introduction to roller conveyors

Views: 0     Author: Site Editor     Publish Time: 2022-05-31      Origin: Site

Introduction to roller conveyors

Roller conveyors are suitable for carrying all kinds of boxes, bags, pallets, and other items. Bulk materials, small items, or irregular items must be shipped in pallets or turnover boxes. It can transport a single material under heavyweight and withstand large impact loads. Connecting and filtering between roller lines is easy. Multiple roller lines and other roller conveyors or specialized machines can be used to form complex logistics transfer systems that meet the needs of different processes. Accumulation rollers can be used to achieve material accumulation and transportation. Next, I would like to introduce the roller conveyor.

Here is the content list:

l What are the characteristics of roller conveyors?

l What are the specifications for the use of roller conveyors?

l What are the applicable scopes of roller conveyors?

What are the characteristics of roller conveyors?

Connections and transitions between roller conveyors are convenient and multiple roller lines and other transfer equipment or specialized machines can be used to form complex logistics transfer systems. Roller conveyors are suitable for conveying items with a flat bottom and are mainly composed of driving rollers, racks, brackets, driving devices, and other parts. It has the characteristics of large conveying capacity, fast speed, and brisk operation, which can realize multi-variety collinear shunt conveying.

The structure of the roller conveyor: from the driving form, it is divided into the powered, unpowered, electric roller, etc. According to the layout, it is divided into horizontal conveying, inclined to convey, and turning to convey.

The size of the roller conveyor: the inner width of the roller conveyor is specified by the customer and can be made according to customer requirements. The standard turning radius of the turning line is 300, 600, 900, 1200mm, etc. Other special specifications can also be adapted according to customer needs. The diameters of the rollers used in the straight section rollers are 38, 50, 60, 76, 89mm, and so on. Design the steering roller taper according to the weight, size, and linear speed of the transported object.

The frame material of the roller conveyor: carbon steel sprayed plastic, stainless steel, aluminum profile.

The power mode of the roller conveyor: reduction motor drive, electric roller drive, and other forms.

The transmission mode of the roller conveyor: single sprocket, double sprocket, O-belt, flat friction transmission belt, timing belt, multi-ribbed belt, etc.

What are the specifications for the use of roller conveyors?

In the application of a gravity roller conveyor, the use of an open or steel cover can avoid increasing the friction of the bearing. Although the application temperature of the bearing can be as high as 170°C, the service temperature of the steel shielded bearing cannot exceed 100°C because the shielding cover will be deformed. When it is outside the range of 0°C to 65°C, special lubrication issues must be considered. In higher temperature applications, the roller conveyor belt load-interval should be increased and moved quickly to reduce the heat absorption of the roller. And it is better to have a heat sink for the drum. The load capacity of the roller conveyor is determined by the load capacity of the bearing and the width of the roller.

What are the applicable scopes of roller conveyors?

Roller conveyors are suitable for carrying a variety of boxes, bags, pallets, and other items. Bulk materials, small items, or irregular items must be shipped in pallets or turnover boxes. Roller conveyors can transport heavier-weight single materials and withstand heavier impact loads. Connecting and filtering between drum lines is easy. Conveyors such as multiple roller lines and specialized machines can form complex logistics conveyor systems to complete a variety of tasks. Process needs. Roller conveyors can use stacking rollers to achieve material storage and transport. The roller conveyor has a simple structure, high reliability, and convenient maintenance.

Huzhou Longwei Import & Export Co., Ltd. has developed a variety of roller conveyors and conducted a lot of tests before leaving the factory to ensure quality. These roller conveyors have strong endurance. If you are in the roller conveyor business, you can consider using our cost-effective products.
